Polaris General 1000 Complete Snow Plow System by KFI Products

Polaris General 1000 Complete Snow Plow System by KFI Products

Clear your big driveway or move gravel, dirt, and more faster and easier than ever by adding this easy-to-install Snow Plow Kit! KFI uses only top-grade steel construction and quality-made components for year after year of reliable plowing.

Kit includes:

• (1) Plow Blade (your choice of size)
• (1) UTV Push Tube
• (1) Vehicle Specific Mount (make sure to select your correct vehicle above)

Important Notes:

• Does NOT include winch or winch mount
• Most Ranger Plow Mounts include lower 2" Receiver Hitch, some Ranger models and All General models do not
• Requires Stock Front Bumper
• 60" blades do not include 2-ply top rubber flap, must be purchased separately
• Does NOT work with all High Lifter Editions or Waterfowl Editions

All Plow Components Feature:

• Complete installation instructions included
• All mounting hardware included
• Powdercoated for maximum durability
• Unlike all other Plow competitors, our components are metal bead blasted before they are powder coated for the best possible finish prep.
• 100% Made in the USA

Straight Blade Specifications:

• Available sizes:
  • 60" ATV / UTV Pro-S Series Plow Blade (Straight) - #105060 - (75 lbs.)
  • 66" UTV Pro-S Series Plow Blade (Straight) - #105066 - (81 lbs.)
  • 72" UTV Pro-S Series Plow Blade (Straight) - #105072 - (85 lbs.)
• Pushes snow straight ahead or to the sides up to 25 degrees
• Added gussets for the wider width
• The 66" & 72" blades include a 7" high 2-ply top rubber flap
• Measures 16” Vertical blade face height with an approximate 21” height with snow flap
• Fully-adjustable blade skids with bolt-on brackets
• Heavy duty 3"-diameter grade-50 steel skid plates
• Blade Constructed of 11 ga steel
• 3/16" Grade 50 Ribbing for a strong bolt-up to the Swivel Tube
• 2-Sided 3/16" x 3.00" Grade 50 Steel Wear Bar
• Wear Bar attached with Heavy Duty Grade 8 Bolts

 UTV Poly Blade Specifications:

• Available sizes:
• 60" ATV / UTV Pro-Poly Series Plow Blade - #105860 - (81 lbs.)
• 66" UTV Pro-Poly Series Plow Blade - #105866 - (82 lbs.)
• 72" UTV Pro-Poly Series Plow Blade - #105872 - (87 lbs.)
• Includes a 7" high 2-ply top rubber flap
• Dual Curvature face for supreme snow moving
• Measures 21” Vertical blade face height with an approximate 27” height with snow flap
• Fully-adjustable blade skids with bolt-on brackets
• Heavy duty 3"-diameter grade-50 steel skid plates
• Flexible Heavy Duty Black Poly face
• 3/16” Grade 50 Steel Rib and Frame construction
• 2-Sided 3/16" x 3.00" Grade 50 Steel Wear Bar
• Wear Bar attached with Heavy Duty Grade 8 Bolts
• Works with KFI ATV & UTV Tubes
• Includes Plow Markers

Pro 2.0 UTV Push Tube (106300):

• Improved Manufacturing
• Easier Install for All Plow Accessories
• Added 2.5" Of Overall Length
• Works With All KFI Plows
• Front Mount Design with 30"+ of lift height
• Heavy Duty 1-1/2" 12 Gage Square Steel Tubing
• Heavy Duty 1/4" Thick 1-1/2" Diameter Grade 50 Pivot Bushings
• 6" Diameter POM Injection Molded Rotator Bushing
• Easy-Pull Pin Blade angle adjustment
• Multi-position Plow Lift Bracket
• 6 five-degree blade pitch adjustments
• 3 blade angle positions that rotate the blade up to 25 Degrees

Model Specific Plow Mount:

• Front-Mount System
• Plate constructed from 3/16" Grade 50 Steel
• All Pin Tabs are constructed from 1/4" Thick Grade 50 Steel
• All Plow tabs are tapered to help reduce hang-ups while trail riding

** Actual Plow Mount may look different than reference photo shown **
